KINO-ADLPS
Giá bán: 0 VNĐ
Giá đã bao gồm VAT
-0%
✔ Sẵn hàng
Mô tả
Mini-ITX SBC support Intel® Alder Lake-PS Core i7/i5/i3 and Celeron® processor, DDR4 SO-DIMM, triple display with DP, HDMI™ and iDPM slots, SATA, Dual Intel 2.5GbE, USB3.2, M.2, RoHS
» Mini-ITX SBC support Intel® Alder Lake-PS Core™ i7/i5/i3 and Celeron® processor (socket)
» Support two 3200MHz DDR4 SO-DIMM
» Triple independent display via HDMI™, DP, iDPM
» Support Dual Intel® I225V/I226V 2.5GbE controller
» Support PCIe Gen3 x4, M.2 M key and M.2 A key expansion
Chi tiết |
|---|
CPU
Mini-ITX SBC support Intel® Alder Lake-PS Core™ i7/i5/i3 and Celeron® processor (socket)
|
Memory
Two 3200 MHz DDR4 SO-DIMMs
|
Display Output
1 x HDMI™ : up to 4096 x 2304@60Hz 1 x Display Port : up to 4096 x 2304 @60Hz 1 x iDPM : 3040 slot (only for iEi eDP/LVDS/VGA module)
|
Ethernet
2 x LAN - LAN1: Intel® I225-V/I226-V 2.5GbE controller LAN2: Intel® I225-V/I226-V 2.5GbE controller
|
I/O Interface
2 x External RS-232/422/485 : RS-485 support AFC 4 x Internal RS-232 : 2x5 pin, P=2.0 2 x External USB 2.0 : Type A 2 x Internal USB 2.0 : 2x4 pin, P=2.0 1 x DIO : 12-bit digital I/O (2x7 pin) 4 x External USB 3.2 Gen2x1 : 10Gb/s
|
Expansion
1 x PCIe x4 : PCIe Gen3 x4 signal (x4 & x2 + x2 & x2 + x1 + x1)
|
Operating Temperature
-10°C ~ 60°C
|
Storage Temperature
-20°C ~ 70°C
|
Humidity
5% ~95%, non-condensing
|
